Xinnuo Purlin Roll Forming Machine: Precision Engineering for CZ Purlins
Xinnuo’s Purlin Roll Forming Machine is a specialized solution engineered for the efficient production of C and Z-shaped purlins, essential structural components in modern steel construction. Designed to meet the demands of industrial, commercial, and residential building projects, this machine combines robust performance with flexible customization, making it a cornerstone for fabricators and construction firms.
|
1
|
Suitable to process
|
Automatic CZ purlin roll forming machine
|
|
2
|
Width of the feeding material
|
as your requirement
|
|
3
|
Roller station
|
11-18 rows or custom as customer’s requirements
|
|
4
|
Thickness of feeding material
|
1.5-3mm or as your requirement
|
|
5
|
Productivity
|
15-20 m/min
|
|
6
|
Rollers’ material
|
45# steel
|
|
7
|
Diameter of shaft
|
70-80mm
|
|
8
|
Voltage
|
380V 50Hz 3phases or as your requirement
|
|
9
|
Wall thickness of main forming machine
|
12-18mm steel plate
|
|
10
|
Main forming machine body
|
300-400 mm H steel
|
|
11
|
Motor power
|
22 kw
|
|
13
|
Weight
|
About 9.8 T
|
|
14
|
Custom
|
According to customer’s requirements
|
At its core, the machine excels in processing materials for automatic CZ purlin production, accommodating diverse project requirements with ease. The width of the feeding material is fully customizable, allowing adaptation to specific design needs—whether for standard or non-standard purlin dimensions. This flexibility extends to the roller station configuration, which ranges from 11 to 18 rows and can be tailored to match unique production specifications, ensuring precise shaping for any purlin profile.
Built to handle sturdy materials, the machine processes metal sheets with a thickness of 1.5–3mm, with options for customization to meet heavier gauge requirements. This capability ensures the produced purlins deliver exceptional structural integrity, ideal for supporting roofs, walls, and frameworks in large-scale structures. With a production speed of 15–20 meters per minute, it balances efficiency and precision, enabling high-volume output without compromising quality—a critical advantage for tight project timelines.
The machine’s durability is anchored in premium components: rollers crafted from 45# steel, known for its high strength and wear resistance, ensuring long-term performance even under continuous operation. The shaft diameter of 70–80mm enhances stability during forming, minimizing vibration and maintaining consistent accuracy. Powered by a 22kw motor, it delivers robust torque to handle thick materials smoothly, while the 380V 50Hz three-phase voltage (customizable to regional standards) ensures compatibility with global power systems.
Structural integrity is further reinforced by the main forming machine’s 12–18mm thick steel plate walls and a 300–400mm H-steel main body, providing a rigid framework that withstands heavy-duty use. With an approximate weight of 9.8 tons, the machine’s solid construction guarantees stability during high-speed production, reducing downtime and extending service life.
Xinnuo prioritizes adaptability, offering comprehensive customization to align with specific customer needs—from roller configurations and material thickness ranges to voltage adjustments. This tailored approach makes the Purlin Roll Forming Machine suitable for diverse applications, including industrial warehouses, logistics centers, agricultural facilities, and commercial complexes.
Backed by Xinnuo’s commitment to quality, this machine ensures reliable, consistent production of CZ purlins that meet strict structural standards. Whether for small-scale projects or large industrial ventures, it delivers the efficiency, durability, and flexibility required to streamline fabrication processes and elevate construction quality.
